McCloskey J6 Jaw Crusher

Jaw Size:
1200mm wide x 864mm
Weight:
64,550kg
Engine:
Volvo D13
Overview
With a large 1200mm x 864mm jaw opening, the J6 is particularly effective in hard rock applications.

The J6 is designed to perform in the toughest applications around the world, with a high TPH thanks to its innovative jaw chamber design.

Material flow is optimised by the wide main and side conveyor and jaw chamber design, evolving the J6 beyond comparable jaw crushers.

Optional extras include factory fit rock hammer, main conveyor feedbox, hopper extensions, and more.

Features

1200mm wide x 864mm single toggle jaw
HD Crawler Tracks
Integrated hydraulic folding hopper
Integrated hydraulic folding stockpiling conveyors
I-beam plate fabricated chassis construction
Large gap between crusher discharge and main conveyor feedboot
Quick release jaw for transport

Tech Specs

Engine
Choice of CAT or Volvo LRC, Tier 4/Stage 5 engines
Transport height
3.9m
Transport length
17.96m
Transport width
3.1m
Weight (base machine)
64,550kg
Crushing chamber
1200mm x 864mm
Stockpile height main conveyor
4.73m
Stockpile height side conveyor
3.99m
Download Full Specs
